SAFAN DARLEY 300-4100 E-Brake 300T Ultra Dual Drive
Have one to sell?
ConditionNew
New
The SafanDarley E-Brake 'Dual Drive' 300T now makes the unique advantages of the E-Brake technology available in the heavy segment of pressure forces up to 330 ton. This breakthrough was possible only thanks to a new SafanDarley invention: the 'Dual Drive' with a double pulley system. Together with the newly developed bearer and the new E-Control Touch Screen control, this results in an unprecedented increase in performance in the heavy segment.
You will have a much stronger position in the market with the new SafanDarley electronic heavy-weight. You can produce the most accurate and constant bending angle across the entire 13 ft range of the machine without the need for crowning. Faster, uses less energy, more ergonomic and durable than any other hydraulic press brake.
Key Features
Efficiency
Up to 30% shorter cycle times
Economy
Up to 50% energy saving
Reliability
Mechanical drive system with 5 year warranty
Stability
Reinforced O-frame for optimum stability
Safety
Integrated safety system and absence of hydraulic oil
Usability
The most functional and intuitive Man-Machine interface
Pressure force in US Ton 330
Bending length in inches 160
Maximum stroke in inches 16
Q size in inches 27
Closing speed in inch/min 213
Bending speed max. in inch/min 48
Return speed in inch/min 213
Motor power in kW 30
Machine weight in lb 48.5
Machine length in inches 216
Machine height in inches 135
SafanDarley EC20 Touch Screen CNC press brake controls
1 Hold to Run operating console
CNC-controlled R-axis
CNC-controlled Y1-Y2 axis (top beam adjustable inclined +/- 0.1 inch)
CNC-controlled back gauge (X-axis) with a wide range
Manual adjustment of 2 back gauge fingers across a linear parallel guide
Daylight of 27.16 inch (Q-dimension)
NSCL II MC Premium top tool mechanical clamping system
NSCR II MC Premium with CNC crowning
2 Support arms (11.81 inch)*
Programmable and integrated safety light guard*
Safety in compliance with CE*
* Standard only for CE countries
